Speed Gate

Turnstile Entrance Speed Gate

Name: Turnstile Entrance Speed Gate
Brand: 2024 Best Selling Turnstile Gates | Low-priced | 2 Years Warranty - Macrosafe
SKU: MS01S
Availability: InStock
Rating: 5 (1 reviews)

Patent: MS01S

Turnstile Entrance MS01S speed gate adopts streamlined design, fashionable and elegant. The perfect combination of stainless steel and tempered glass makes it complement modern architecture and enhance the company's image.

Online Inquiry

Advantages Specifications Dimension Options Gallery

Advantages

Turnstile Entrance Video:

Turnstile Entrance Description:

Turnstile is a robust device that improves people flow management and safety for various buildings and facilities. When it comes with different access control system, they allow authorized users to enter designated areas smoothly, while preventing those without credentials.
For entrance security control, a turnstile is always the ideal and cost-effective solution no matter indoor or outdoor, no matter for manned or unmanned.

Turnstile Entrance Video:

Turnstile Entrance Variations:

1. Customizable Security Height
The height of the tempered glass barrier is adjustable (900mm–1600mm), designed to align with the security requirements of different environments. Ideal for commercial complexes, transportation hubs, and high-risk facilities, it ensures tailored protection for varying threat levels.

2. Adaptive Passage Solutions
Dual-mode configurations to optimize traffic flow:
• Standard Passage (600mm): Streamlined design for high-traffic efficiency.
• ADA-Compliant Wide Passage (900mm): Ensures barrier-free accessibility for wheelchairs and mobility aids, meeting ADA accessibility standards.

3. Premium Surface Finishes
Choose from two professional-grade finishes:
▸ Brushed Stainless Steel: Crafted from 304 stainless steel with 16-step polishing for a sleek, commercial-grade appearance.
▸ Eco-Friendly Powder Coating: Customizable via RAL color codes, featuring ≥80μm coating thickness and adhesion durability.

Turnstile Entrance Applications:

With a modern & narrow profile design and technology of the future, MS01S speed gate is one of the best choices when you are considering adding turnstiles for the entrance of your facility. It plays an important role in crowd dispersal in public transportation systems and public facilities, such as airports, subways, high-speed railways, bus stations, as well as art centers, museums, exhibition halls, gymnasiums, etc.

Turnstile Entrance Features:

Narrow and fashional design；

Photoelectric sensors detects including unauthorized entry, tailgating , illegal intrusion, reverse intrusion, etc;

With servo motor, MCBF of it up to 15 millions;

Different heights of glass available to prevent pedestrians from climbing over;

Short opening time of 0.3 seconds for a high throughflow frequency;

Audible & visible alerts when detect unauthorized entry;

Passage width from 600-900mm, suitable for wheelchairs and prams;

Various LED indicators clearly show the passage direction and status;

Can be integrated with any type of access control systems;

Simple installation, easy operation and low maintenance;

Model No.	MS01S
Cabinet Material	SUS304/316 stainless steel
Swing Material	Plexi-glass or Tempered glass
Unit Dimension(WLH)	14001201000mm/1200120980mm
Glass height（from floor）	900-1600mm
Passing Direction	Uni-directional/Bi-directional
Photoelectric Sensor	8 pairs/16 Pairs
Passage Width	600-900mm
Opening/Closing	0.3 seconds
Flow Rate	45-50 person/min
Mechanism	Brushless motor/Servo motor
Power Supply	AC100-240V,50Hz
Working Voltage	DC source 24 V
Application	Indoor and outdoor(Shelter)
Working Temperature	-25℃~+70℃
Operation Humidity	0 ~ 95% (No freeze)
MCBF	15,000,000 cycles
Anti-panic mode	Automatically open when power off
Communication	Dry contact, Relay signal, RS485

Flexible configurations available optionally up on request.

01 Cabinet Material

Generally cabinets are made from brushed 304 stainless steel.
The following materials are also available：

Brushed 304 stainless steel（Regular）

Brushed 316 stainless steel

Polished 304 stainless steel

Polished 316 stainless steel

02 Cabinet Anti-fingerprint process

Anti-fingerprint steel treatment is based on the original 304 stainless steel, after vacuum coating, forming a layer of bright protective film on the surface also has the function of anti-fingerprint.

03 Cabinet Colors

In addition to the primary color of stainless steel, you can also choose other colors, such as white, black, brown, etc., to make it more coordinated with your building.

04 Glass Etching

Support personalize glass barriers and side panels with etched artwork, logos or directions.

05 Panels Material

You can select plexi-glass or tempered glass for swing panels and/or filter panels.

06 Mechanism

Configured brushless motor by default.
You can choose to upgrade it with servo motor, make it perform even better beyond your expect.
High swing arm(ground clearance≥1.2meter) configured servo motor by default.

07 Custom Illumination

Besides regular LED indicator, static or dynamic lightings hidden in the glass panels are also optional ,which meets the different needs of various occasions.

*More options and customizations available on request.
